89XDB/89XDE
High Flow Inflators
High Flow Inflators
The 89XDB Automatic Tyre Inflator incorporates a high flow ½” valve capable of delivering in excess of 4,000 litres/min (141 cfm) at a maximum of 10 bar / 145 psi pressure. The heavy duty, weatherproof and vandal resistant enclosure makes it ideal choice for any indoor or outdoor application which requires a high flow rate. Used with a 4-way manifold kit, 89XDB is able to inflate multiple tyres simultaneously, maximising inflation productivity. It is available in a dual display model, 89XDE.
- High flow and high pressure inflation up to 145 psi / 10 bar
- Rugged and durable IP66 rated diecast aluminium enclosure
- Suitable for use with standard or large bore valves and core extraction tools
Technical Specifications
| Construction | Diecast aluminium wall enclosure (IP66) |
| Dimension | 269 W x 285 H x 106 D mm |
| Power requirements | 220V-240VAC (optional 12VDC or 100~120VAC) |
| Units of measurement | psi / kPa / bar / kg/cm² |
| Operating range | 5-145 psi / 35-1000 kPa / 0.3-10.0 bar / 0.4-10.2 kg/cm² |
| Accuracy | +/- 0.5% FS |
